9-stage chrome-free pretreatment. Three durability levels. Full RAL range. QUALICOAT Seaside and AAMA certified — applied entirely in-house.
CANEX operates a complete in-house powder coating line — one of the few aluminum extrusion facilities in Egypt to hold both QUALICOAT Seaside and AAMA certification simultaneously. The line processes profiles of up to 13 meters in length, applying polyester powder in any RAL color to profiles that emerge from our extrusion presses and enter the coating line without leaving the facility.
The process begins with a 9-stage chrome-free pretreatment tunnel — designed to EU environmental directives — that thoroughly cleans, etches, and chemically converts the aluminum surface before any powder is applied. This pretreatment stage is critical: it determines adhesion, corrosion resistance, and coating life far more than the powder itself.
We offer three durability grades — Standard, Super Durable, and Hyper Durable — allowing architects and engineers to precisely match coating lifetime to project exposure conditions. Color consistency is maintained through batch control, and custom RAL colors are available on request with sample approval.
CANEX's pretreatment tunnel is a chrome-free, environmentally compliant 9-stage process — matching or exceeding the requirements of QUALICOAT Seaside certification. No chrome compounds are used at any stage, in full compliance with EU REACH regulations.
01
Degreasing
02
Etching
03
Rinse 1
04
Rinse 2
05
Rinse 3
06
Chrome-Free
Conversion
07
Drying
Oven
08
Powder
Application
09
Curing Oven
& QC
Complete technical specifications for CANEX in-house powder coating — from pretreatment chemistry to finished film properties.
| Pretreatment | 9-stage chrome-free tunnel |
| Durability Grades | Standard / Super Durable / Hyper Durable |
| Color Range | Full RAL; custom colors available on request |
| Certifications | QUALICOAT Seaside + AAMA |
| Film Thickness | 60–120 μm standard; up to 200 μm on request |
| Adhesion | Cross-cut test ISO 2409: Grade 0 |
| Gloss Options | Matte, satin, gloss (as per powder specification) |
| Environmental | Chrome-free; EU REACH directive compliant |
| Max Profile Length | Up to 13 meters (matched to extrusion length) |
CANEX offers three powder grades to match coating durability with project exposure conditions — from sheltered interiors to aggressive coastal environments.
Standard Durability
For interior applications and protected exterior locations with moderate UV and weather exposure. Typical service life 10+ years in sheltered conditions. Cost-efficient for most commercial interior projects.
Super Durable
For standard exterior exposure — facades, window frames, and curtain walls in normal urban or suburban environments. Enhanced UV resistance and color retention. Exceeds QUALICOAT Class 1 requirements. Typical service life 15+ years.
Hyper Durable
For aggressive coastal environments with salt spray, high UV, and humidity. Meets QUALICOAT Seaside class — the most demanding architectural coating standard. Specified for seafront buildings, marine structures, and Middle East exterior applications.
Two internationally recognized certification bodies independently audit CANEX's powder coating process and output — giving specifiers, architects, and contractors documented performance assurance.
Coat
Seaside
QUALICOAT Seaside
QUALICOAT is the leading international quality label for powder coating on architectural aluminum. The Seaside class is the highest level — specifically certifying that the coating system (pretreatment chemistry, powder quality, application process, and curing) meets the stringent requirements for environments with high salt content and aggressive exposure. CANEX is one of a small number of facilities in Africa and the Middle East to hold this designation.
Certified
AAMA Certified
The American Architectural Manufacturers Association (AAMA) sets voluntary performance standards for coatings on architectural aluminum in North American markets. AAMA certification confirms that CANEX's powder coating system meets or exceeds these specifications — enabling CANEX-coated profiles to be specified on projects requiring AAMA compliance, including US and Canadian exports and international projects using North American design standards.
CANEX powder coating is specified on projects across architecture, construction, and industrial manufacturing — wherever color, durability, and corrosion resistance are required simultaneously.
Architectural Facades
Window & Door Frames
Curtain Wall Systems
Furniture & Interior Fixtures
Marine Structures
Outdoor Furniture
Industrial Enclosures
Retail & Display Fixtures
Get a quote for your specific requirements. Our engineering team responds within 48 hours.
